Bottom homogenizer, inline dispersing machine, 3D butterfly stirrer

Personal care products cover a wide range of products, mainly divided into three categories of products: shampoo, shower gel, hair conditioner. The general demand is large, and three-in-one can be produced in the same production line, which requires the equipment to reflect high comprehensive utilization.

Dilute THE AES (if the raw material is 75% concentration) and dissolve the AES with water in a highly efficient mixture.

2. According to different products and formulations, add dozens of other materials required for mixing and dispersing, including silicone oil, xanthan gum or other thickeners, the essence, powder or liquid, etc.

3. Fully dissolve, disperse and homogenize in the tank.

1. High concentration AES has poor fluidity and high viscosity, the dispersing efficiency is low when AES is directly added to the main tank and treated with coaxial stirrer.

2. Transfer of drum AES to the main tank requires considerable manual labor.

3. Many bubbles will be generated in an unsealed environment by conventional bottom homogenization equipment.

4. Some products are harsh to silicone oil treatment, and the traditional coaxial stirring and bottom homogenization method cannot meet the requirements.

5. Have poor effect with products with high viscosity .

1. Adopt FLUKO FDC or FDH series inline high shear dispersing emulsifier to shear AES and water.

2. Use FLUKO FDE series bottom inline high shear dispersing emulsifier to make external circulation.

3. 3D butterfly stirrer.

1.FDE series bottom inline high shear dispersing emulsifier, with external powder and liquid suction functions, easy to achieve the silicon oil inline shearing process, make the silicon oil coating more uniform; At the same time, the powder can be added inline and mixed instantaneously, effectively avoiding the problem of dust flying caused by the addition of light powder from the tank.

2. EF34 series three-dimensional butterfly stirrer can dissolve the materials with high viscosity in the tank and disperse them quickly; Realize "one machine" to complete the core process of premixing and cooling in the tank.

3. FDC series inline high shear machine, small cavity, high energy density, and large displacement rotor/stator design, which can adapt to high viscosity working condition, ensure the normal processing of high viscosity products, and improve the efficiency of dissolving AES through inline dilution method of once cycle.
